ASTM A123 Nema 20C Bandeja de Cabo Cabo Cabo Pista Do Duto Fabricação Sistema de Apoio

FOB Referência Preço:Obter Cotação Imediata
US$ 1,00 - US$ 3,50 / Medidor | 100 Medidor/medidores (Min. Ordem)
relatório de Atividades Suspeitas
Visão Geral
Detalhes Rápidos
Lugar de origem:
Jiangsu, China (Mainland)
Número do Modelo:
Calha perfurada ou ventilada
Aço, Q235, SS304, SS316, FRP
50-900 milímetros
2.44mm/3 m/6 m, 1-6 metros
Altura do trilho lateral:
12-200 milímetros
Carga de funcionamento máxima:
De acordo com o tamanho diferente
Prata, laranja, vermelho, branco
Electro quente mergulhado galvanizado, zinco chapeado, Pó Revestido
Slot ou Não:
Besca Padrão ou de acordo com requierments de cliente
1-2.5 milímetros
Capacidade de fornecimento
Capacidade de fornecimento:
500 Ton/Tons per Month
Embalagem e entrega
De acordo com exigências de clientes
Tempo de execução: :
Shipped in 5 days after payment


Company Information

Company Introduction of Perforated Cable Tray


Shanghai Besca Industrial Co., Ltd. is China’s leading Cable Support Systems and Pipe Support Systems manufacturerand supplier with over 30 years industrial experiences. BESCA specializes in Cable Tray, Cable Trunking, Wire Way, Cable Ladder, Wire Mesh Cable Tray, Strut Channel systems and accessories.


BESCA operates a factory located in Jiangsu Province, Zhenjiang Besca Electrical Manufacturing Co., Ltd.


BESCA is an ISO9001: 2008 company of management systems.


Besca passed: UL/cUL (File No. E359562), CE and NEMA Ve1, IEC 61537.


BESCA has already exported to over 30 countries, obtaining good reputations from worldwide.


BESCA provides OEM service.







BESCA Certificates of Perforated Cable Tray Support Systems






 ASTM A123 Nema 20C Cable Tray Cable Duct Cable Raceway Support System Manufacture
1. Better price quality
2. Biggest manufacturer
4. Flexible & fast installation


Details of Perforated Cable Tray Support Systems as follow:




Electro - Zinc Plated Cable Tray :


All accessories for Cable Tray Support Systems:




Hot dip Galvanized Cable Tray Support Systems


Powder Coated Cable Tray Support Systems




Dimension of Cable Tray Support Systems

::...900mm:...600mmor 2400mm0.8/1.2/1.5/2.0/2.5......

We also sell various kinds of cable tray according to the drawing or picture and requirements of customers


Material of Cable Tray Support Systems:

Q235B Steel (Chinese standard steel), SS304, SS316


Surface Finish of Cable Tray Support Systems:

Electro zinc plated – for indoor use to BS EN 12329-2000, 12microns thick.

Hot Dipped Galvanized – for outdoor use to BS EN 1461-1999, between 60 and 80 microns thick

Electrolytic Polishing – for stainless steel use

Powder Coated


The advantages of our Cable Tray Support Systems :

1. Low cost, significant cost savings compared to standard traditional tray products.

2. Light in weight, wide range of sizes.

3. Fast heat dispersion.

4. Strong enough to withstand short circuits. Provides strength, rigidity without additional hardware.

5. Adapts to difficult architectural designs to accommodate changes in direction and elevation of cable runs.

6.Flexible, easy and fast installation. Design allows cable exit or entry at any point.

7. Cables can be secured to clamps or ties.

8.Various hardware accessories available to fix, support and install.

9. Safe smooth edge design to protect cable.

10.Easy for line check and cleaning , easy maintained.


All sharp ends are cut off to protect cables. Weight loading capacity is 27% stronger than traditional cable trays and cable ladders.


If you are interested in our product, please feel free to tell me and we hope can contact with you further in both English or Spanish.

We also can offer you our free samples.
Hope we could cooperate with each other, the best support and service will be provided to you from BESCA.



 Our Workshop welcome to your visiting!
